FTARP03 NTC 1m PVC cable stainless steel waterproof probe 10K resistance RTD temperature sensor
$3.33
- Description
- Additional information
Description
FTARP03 series polish rod probe head waterproof RTD temperature sensor
|
Model number |
Type |
Measuring range |
Related product |
|
FTARP03-PT100 |
PT100 |
-50-150 °C |
|
|
FTARP03-CU50 |
Cu50 |
-50-150 °C |
|
|
FTARP03-NTC |
NTC |
PVC: -5-80 °C; Silica gel: -50-180 °C |
Visiting… |
|
Model number |
FTARP03 series |
|
Mounting form |
Polish rod probe |
|
Resistacne |
NTC: 10KΩ at 25°C |
|
B value |
NTC: 3435K at 25/85°C; 3950K at 25/85°C |
|
Probe material |
Stainless steel |
|
Probe diameter |
5, 6mm |
|
Probe length |
30mm, 50mm, can be customized |
|
Cable material |
PVC; Silica gel |
|
Cable length |
Standard is 2m, customer can select 1, 3 ,5, 10m or specify the cable length |
|
Thermal response time |
<12s |
|
Insulating resistance |
20MΩ min |
|
Purpose |
Cold storage, Pharmaceutical GMP monitoring system, Telecommunications room, Beer production, Building automation control, Incubation, Aquaculture, Greenhouse, Air conditioning, Household refrigerators |
|
No |
Model Number |
Probe Diameter |
Probe Length |
Resistacne |
B Value |
Cabel Material |
Cable Length |
Related Product |
|
1 |
FTARP03-NTC-D5(-D6)L50R10B3435(B3950)P0.5 |
5mm; 6mm |
50mm |
10K |
3435K; 3950K |
PVC |
0.5m |
|
|
2 |
FTARP03-NTC-D5(-D6)L50R10(R3)B3435(B3950)P1 |
5mm; 6mm |
50mm |
10K; 3K |
3435K; 3950K |
PVC |
1m |
Visiting… |
|
3 |
FTARP03-NTC-D5(-D6)L50R10B3435(B3950)P2 |
5mm; 6mm |
50mm |
10K |
3435K; 3950K |
PVC |
2m |
|
|
4 |
FTARP03-NTC-D5(-D6)L50R10B3435(B3950)S0.5 |
5mm; 6mm |
50mm |
10K |
3435K; 3950K |
Silica gel |
0.5m |
|
|
5 |
FTARP03-NTC-D5(-D6)L50R10B3435(B3950)S1 |
5mm; 6mm |
50mm |
10K |
3435K; 3950K |
Silica gel |
1m |
|
|
6 |
FTARP03-NTC-D5(-D6)L50R10B3435(B3950)S2 |
5mm; 6mm |
50mm |
10K |
3435K; 3950K |
Silica gel |
2m |
|
|
7 |
FTARP03-NTC-D5(-D6)L50R10B3435(B3950)S3 |
5mm; 6mm |
50mm |
10K |
3435K; 3950K |
Silica gel |
3m |
|
|
8 |
FTARP03-NTC-D5(-D6)L50R10B3435(B3950)S5 |
5mm; 6mm |
50mm |
10K |
3435K; 3950K |
Silica gel |
5m |
Additional information
| Cable Length | 1M |
|---|---|
| Theory | Temperature Sensor |
| Usage | Industrial |
| Model Number | FTARP03-NTC-D5 6L50R10B3435P1 |
| Max Measuring Temperature | 100°C – 119°C |
| Display Type | Analog |
| Power Type | None |
| Display Size | 2.0 – 3.9 Inches |
| Style | Standing Station |
| Brand Name | Finglai |
| Origin | Mainland China |
| Certification | CE |
